Degree of Protection: IP65 Watertight/ Oiltight
Contact Type: Single Pole, Double Pole
Maximum Voltage: 250V AC/DC
Thermal Current: 5A
Minimum Applicable Load: 5V AC/DC, 1mA
Contact material: Gold--plated silver
Tminal Style: 110” Solder/ Quick Connect
Operating Temperature: -25℃to +55℃
Operating Humidity: 45 to 85%RH
Contact Resistance: 50MΩmaximum
Insulation Resistance: 100MΩminimum (500V DC megger)
Vibration Resistance: 10 to 55Hz, amplitude 1.2mm p-p
Degree of Protection: >10g
Electrical Life: 100,000 operations minimum (at full rated load)
Mechanical Life
Maintained: 1,000,000 operations minimum
Momentary: 1,000,000 operations minimum
Dielectrical Life
Switch Unit: 2,000V AC, 1 min. between live/dead part and terminals of different poles;
1,000V AC, 1 minute between terminals of the same pole;
1,500V AC, 1 minute between contact and lamp terminals.
Illumination Unit: 2,000V AC, 1 min. between live part/ground
Soldering Temperature: 20W/5 seconds or 260℃/3 seconds
